SKU: MZ-RS081

MOZA R12 V2 DIRECT DRIVE BASE (12 NM)

With a powerful 12 Nm Direct Drive servo motor, the MOZA R12 V2 Direct Drive Wheel Base offers a realistic steering feel and precise feedback from the road surface. Thanks to innovative NexGen 3.0 force feedback algorithms and state-of-the-art motor technology, it delivers an incomparable driving experience. The robust aerospace aluminum housing and intelligent temperature control system ensure maximum durability and consistent performance.

€565.00 (συμπ. ΦΠΑ)

Σε απόθεμα

Παράδοση:
Σε απόθεμα

Περιγραφή

Features

  • 12 Nm Direct Drive for precise force feedback
  • High-quality housing made of aerospace aluminum for maximum stability
  • 1000 Hz USB sampling rate for delay-free input
  • Precise 21-bit sensors with high resolution for precise steering maneuver
  • Unlimited steering angle for maximum flexibility
  • Intelligent temperature control for constant performance



Advanced technology for maximum control

The MOZA R12 V2 is equipped with an advanced helical-pole servo motor that provides exceptional smoothness and highly detailed force feedback. The 18-slot, 16-pole design minimizes torque ripple and electromagnetic vibration, resulting in a smooth and direct steering feel. Through the use of high-performance magnets and an optimized motor structure, the Wheel Base delivers an exceptional balance of torque and energy efficiency.



High-quality materials and innovative design

The housing of the MOZA R12 V2 is made of high-quality aerospace aluminum, which not only ensures a classy look, but also maximum stability. Thanks to its compact design, the wheel base fits into any simracing setup and can be mounted on a cockpit or with an optional table clamp. In addition, an industrial slip ring design ensures durable and stable data transmission between the steering wheel and wheel base.



Intelligent control with MOZA Pit House

With the MOZA Pit House software, all settings of the R12 V2 can be customized. From force feedback intensity to mechanical friction and sensitivity to road feedback — every fine-tuning can be made for the perfect driving experience. Thanks to the cloud-based mobile app control, adjustments can even be made in real time during the race.



Safety and comfort at the highest level

The MOZA R12 V2 features intelligent hand-off protection, which detects when hands are removed from the steering wheel and automatically reduces vibrations to prevent accidents. The improved temperature control system permanently monitors the engine temperature and dynamically adjusts the power to ensure consistently high performance — even during intensive racing sessions.





Specifications



Additional information

Brand MOZA®
Platform +, PC
Peak torque 10 – 15 Nm
Drive Type Direct Drive
Max Wheel Rotation Limitless
Housing Material Aluminum
Housing Color Black
Encoder 21-bit
Peak Power 216W
Input Voltage 110V~220V AC —>36V DC
USB Refresh Rate 1000 Hz
App Functions Supported
Quick Release Supported
Connection Ports Power, USB, Pedal, Dash, Shifter, Handbrake, E‑Stop
Fixing Method 4‑hole bottom mount
Desk Clamp Optional
E‑Stop Optional
Online Firmware Update Supported
Product size 226 x 157 x 124 mm

Επιπρόσθετες Πληροφορίες

Βάρος 7 κ.
Brand

Διαθέσιμα αξεσουάρ
