SKU: SM-AlphaM-BW

SIMAGIC ALPHA MINI Wheel Base

Forget about the out-dated belt-drive system. Direct drive is the only known way to achieve real-life race car steering dynamic range. It’s just a pure connection to the road behind the wheel.

Connect your wheel directly to a fast response direct drive motor for maximized simulation of force feedback. This is the only way toward a professional sim racing.

​As our entry-level sim racing wheel base, ALPHA MINI managed to have the best range of torque for sim racing. The highest force required is usually when you hit the curbs or at the bottom of this hill.

6-8 Nm is what usual people found enough for sim racing, the remaining 2-4 Nm is used to minimize the force feedback clipping, reflect sudden change for force feedback.

Professional race drivers were invited during the design process. Iterations were made to best simulate the real racing. To unleash the full capability of the servo motor, Alpha mini uses three CPUs to process signals. The result is astonishing. Ultimate refresh rate and update rate are achieved thanks to the Tri-CPU structure. 1000 Hz refresh rate for USB communication, 40000 Hz update rate for force feedback controls.

599.00

Σε απόθεμα

Παράδοση:
Σε απόθεμα

Περιγραφή

Specifications

Maximum torque: 15Nm

Finishing – CNC aluminum housing with an anodizing surface

Motor – Three phase servo motor optimized for sim racing uses

Max Toque – 10 Nm

Power Requirement – 100-220V AC, 50/60Hz (Use adapter comes standard with the device only)

Platform – PC only, supports all major PC games like F1 2019, Dirt Rally, Assetto Corsa, rFactor 2 etc.

Connection – USB-B for connection to PC, Plug and Play, Reset button available for quick reset

Location Sensor – 16385 Pulses per revolution

Refresh Rate – 1000 Hz for in-game data communication, 40000 Hz for force feedback control

Standard Warranty – 12 months

Manuals

Alpha Manager

Alpha Base Manual

Drilling Template

Compatibility List

iRacing Tuning Tutorial

Επιπρόσθετες Πληροφορίες

Βάρος 17 kg
